Technical Specifications66 specs
Additional Contents
Fans Included
Yes
Included Fans
4x 120 mm
Additional Information
Model Number
V100RW
Gtin
4718466017918
Back Connect
Back Connect
Yes
Cable Specifications
Riser Cable Included
No
Case
Case Type
Mid Tower
Case Features
I O Position
Side
Side Panel
with window
Vertical Gpu Mount
No
Adjustable Vertical Gpu Bracket
No
Front Door
No
Cable Management
Yes
Filters Included
Yes
Filter Position
Bottom
Noise Dampening
No
Mainboard Slide Tray
No
Transport System
No
Colour
Primary Colour
White
Fan Main Colour Frame
White
Compliance
Compliance Documents
Lian Li Case Compliance and Safety
Dimensions
Length Depth
446 mm
Width
235.5 mm
Height
484.65 mm
Display
Display Included
No
Drive Bays
Max 2 5 Inch Drives
1
Max 3 5 Inch Drives
1
Max 5 25 Inch Drives
0
Hot Swap Drive Bays
No
Expansion Slots
Expansion Slots Pci Slots
7
External Ports
Front I O Usb Type C Ports Total
1
Front I O Usb Type A Ports Total
2
Usb 3 1 External Type C
1
Usb 3 0 External Type A
2
Audio Outputs Inputs
1x output / input comb. (3.5 mm jack, 4-pin, TRRS)
Card Reader
No
Fan Header
Fan Controller Fan Hub
No
Fan Support
Max Number Of Fans
9
Case Fan Support Bottom
120mm Fan (2x)
Case Fan Support Side
120mm Fan (3x)
Case Fan Support Top
120mm Fan (3x), 140mm Fan (2x)
Case Fan Support Rear
120mm Fan (1x), 140mm Fan (1x)
120 Mm Fans
9
140 Mm Fans
3
Features
Housing Feedthrough
No
Internal Dimensions
Max Cooler Height
178 mm
Max Gpu Length
420 mm
Max Psu Length Depth
220 mm
Lighting
Lighting Rgb
Yes
Rgb Controller
Yes
Rgb Type
ARGB / DRGB
Lighting Colour
RGB
Materials
Materials
Steel, Tempered Glass
Motherboard Support
Compatible Motherboard Formats
E-ATX, ATX, Micro-ATX, Mini-ITX
Max Motherboard Format
E-ATX
Mounting
Case Vesa Mountable
No
Internal Monitor Mount
No
Power Supply
Psu Included
No
Psu Format
ATX
Power Supply Position
rear bottom
Product Series
Product Series Family
Vector V100
Radiator Support
Radiator Aio Support Top
360mm Radiator
Max Radiator Compatibility
1x Triple (360 mm)
