Lian Li O11D EVO XL - Black
MPN: O11DEXL-X
Key specifications
Max GPU460.0 mm
Max Cooler167.0 mm
Max PSU220.0 mm
Form factorUnknown
Best indexed price
Price unavailable
Retailer offers
Amazon UKProduct link
Find on AmazoneBay UKSearch link
Search eBayMore retailers coming
We only list a retailer once we hold verified offer data for it. No placeholder prices, ever.
Indexed prices are snapshots, not live quotes. Confirm price, stock and delivery on the retailer's site — checkout completes there.
We may earn a commission from these links. How it works
Fit check
Supports up to 460.0mm GPU clearance.
Supports up to 167.0mm CPU cooler height.
Full Specifications71 fields
Additional Contents
Fans Included
No
Included Fans
None
Additional Information
Model Number
O11DEXL-X
Gtin
4718466013712
Back Connect
Back Connect
No
Cable Specifications
Riser Cable Included
No
Case
Case Type
Full Tower
Case Features
I O Position
Front
Side Panel
with window
Vertical Gpu Mount
No
Adjustable Vertical Gpu Bracket
No
Front Door
No
Cable Management
Yes
Filters Included
Yes
Filter Position
Top, Bottom, Side
Noise Dampening
No
Mainboard Slide Tray
No
Remote Included
No
Transport System
No
Colour
Primary Colour
Black
Secondary Colour
Transparent
Compliance
Compliance Documents
Lian Li Case Compliance and Safety
Dimensions
Length Depth
522 mm
Width
304 mm
Height
531.9 mm
Weight
17 kg
Display
Display Included
No
Drive Bays
Max 2 5 Inch Drives
7
Max 3 5 Inch Drives
4
Max 5 25 Inch Drives
0
2 5 Inch Internal Drive Bay
3
1x 3 5 1x 2 5 Inch Internal Drive Bays Combined
4
Hot Swap Drive Bays
No
Expansion Slots
Expansion Slots Pci Slots
8
External Ports
Front I O Usb Type C Ports Total
1
Front I O Usb Type A Ports Total
4
Usb 3 1 External Type C
1
Usb 3 0 External Type A
4
Audio Outputs Inputs
1x output / input comb. (3.5 mm jack, 4-pin, TRRS)
Card Reader
No
Fan Header
Fan Controller Fan Hub
No
Fan Support
Case Fan Support Rear
120mm Fan (2x)
Case Fan Support Top
120mm Fan (3x), 140mm Fan (3x)
Case Fan Support Side
120mm Fan (3x), 140mm Fan (3x)
Case Fan Support Bottom
120mm Fan (3x), 140mm Fan (3x)
Max Number Of Fans
11
120 Mm Fans
11
140 Mm Fans
9
Features
Housing Feedthrough
No
Internal Dimensions
Max Cooler Height
167 mm
Max Gpu Length
460 mm
Max Psu Length Depth
220 mm
Lighting
Lighting Rgb
Yes
Rgb Controller
Yes
Lighting Colour
RGB
Materials
Materials
Aluminium, Steel, Tempered Glass
Motherboard Support
Compatible Motherboard Formats
E-ATX, ATX, Micro-ATX, Mini-ITX
Max Motherboard Format
E-ATX
Mounting
Internal Monitor Mount
No
Case Vesa Mountable
No
Power Supply
Psu Included
No
Psu Format
ATX
Power Supply Position
rear side
Product Series
Product Series Family
O11D
Radiator Support
Radiator Aio Support Side
240mm Radiator, 280mm Radiator, 360mm Radiator, 420mm Radiator
Max Radiator Compatibility
3x Triple (420 mm)
Radiator Aio Support Bottom
240mm Radiator, 280mm Radiator, 360mm Radiator, 480mm Radiator
Radiator Aio Support Top
240mm Radiator, 280mm Radiator, 360mm Radiator, 420mm Radiator
