Technical Specifications66 specs
Additional Contents
Fans Included
No
Included Fans
None
Additional Information
Model Number
A3W-WDG
Gtin
4718466017574
Back Connect
Back Connect
No
Cable Specifications
Riser Cable Included
No
Case
Case Type
Mini Case
Case Features
I O Position
Front
Side Panel
with window
Vertical Gpu Mount
No
Adjustable Vertical Gpu Bracket
No
Front Door
No
Cable Management
Yes
Filters Included
Yes
Filter Position
Bottom
Noise Dampening
No
Mainboard Slide Tray
No
Transport System
No
Colour
Primary Colour
White
Compliance
Compliance Documents
Lian Li Case Compliance and Safety
Dimensions
Length Depth
443 mm
Width
194 mm
Height
321.5 mm
Weight
5 kg
Display
Display Included
No
Drive Bays
Max 2 5 Inch Drives
3
Max 3 5 Inch Drives
1
Max 5 25 Inch Drives
0
2 5 Inch Internal Drive Bay
2
1x 3 5 1x 2 5 Inch Internal Drive Bays Combined
1
Hot Swap Drive Bays
No
Expansion Slots
Expansion Slots Pci Slots
4
External Ports
Front I O Usb Type C Ports Total
1
Front I O Usb Type A Ports Total
2
Usb 3 1 External Type C
1
Usb 3 0 External Type A
2
Audio Outputs Inputs
1x output + 1x input (3.5 mm jack, 3-pin, TRS)
Card Reader
No
Fan Header
Fan Controller Fan Hub
No
Fan Support
Max Number Of Fans
10
Case Fan Support Bottom
120mm Fan (2×)
Case Fan Support Side
120mm Fan (3x), 140mm Fan (2x)
Case Fan Support Rear
120mm Fan (1x)
Case Fan Support Top
120mm Fan (3x)
120 Mm Fans
10
140 Mm Fans
2
Features
Housing Feedthrough
No
Internal Dimensions
Max Cooler Height
165 mm
Max Gpu Length
415 mm
Max Psu Length Depth
220 mm
Lighting
Lighting Rgb
No
Materials
Materials
Plastic, Tempered Glass, Wood, SPCC (steel)
Motherboard Support
Compatible Motherboard Formats
Micro-ATX, Mini-ITX
Max Motherboard Format
Micro-ATX
Mounting
Case Vesa Mountable
No
Internal Monitor Mount
No
Power Supply
Psu Included
No
Psu Format
ATX, SFX-L, SFX
Power Supply Position
Internal
Radiator Support
Radiator Aio Support Top
240mm Radiator, 360mm Radiator
Radiator Aio Support Bottom
240mm Radiator, 360mm Radiator
Max Radiator Compatibility
2x Triple (360 mm)
Radiator Aio Support Side
240mm Radiator, 280mm Radiator, 360mm Radiator
