CasesFractal Design
Fractal Design North XL Chalk White Full Tower Case
MPN: FD-C-NOR1X-03
Key specifications
Max GPU413.0 mm
Max Cooler185.0 mm
Max PSU290 mm
Form factorMid Tower
Full Specifications101 fields
Additional Contents
Fans Included
Yes
Included Fans
3x 140 mm
Additional Information
Model Number
FD-C-NOR1X-03
Gtin
7340172706557
Back Connect
Back Connect
No
Cable Specifications
Riser Cable Included
No
Case
Case Type
Mid Tower
Case Features
I O Position
Top
Side Panel
with mesh
Vertical Gpu Mount
No
Adjustable Vertical Gpu Bracket
No
Front Door
No
Cable Management
Yes
Filters Included
Yes
Filter Position
Bottom, Front
Noise Dampening
No
Mainboard Slide Tray
No
Transport System
No
Chassis Physical Specifications
Colour
White
Chassis Construction Materials
Steel
Dimensions
240 X 509 X 503 (WxHxD mm)
Package Type
-
Please Note
-
Clearances
Cable Routing Space
29 mm
Colour
Primary Colour
White
Connectivity
Card Reader
No
Core Chassis Specifications
Edition
Fractal North XL Mesh - Chalk White
Case Form Factor
Mid Tower
Motherboard Form Factor
ATX
E-ATX (330 mm)
MicroATX
Mini-ITX
Back Connect Compatible
No
Dimensions
Length Depth
503 mm
Width
240 mm
Height
509 mm
Weight
9.7 kg
Display
Display Included
No
Drive Bays
Max 2 5 Inch Drives
4
Max 3 5 Inch Drives
2
Max 5 25 Inch Drives
0
2 5 Inch Internal Drive Bay
2
1x 3 5 1x 2 5 Inch Internal Drive Bays Combined
2
Hot Swap Drive Bays
No
Expansion Slots
Expansion Slots Pci Slots
7
External Ports
Front I O Usb Type C Ports Total
1
Front I O Usb Type A Ports Total
2
Usb 3 2 External Type C
1
Usb 3 0 External Type A
2
Audio Outputs Inputs
1x output + 1x input (3.5 mm jack, 3-pin, TRS)
Fan Header
Fan Controller Fan Hub
No
Fans & Filters
Fan Bays
9 x 120mm / 8x 140mm
Fan Controller Hub
-
Dust Filters
Front
PSU
Fan Support
Case Fan Support Rear
120mm Fan (1x), 140mm Fan (1x)
Case Fan Support Top
120mm Fan (3x), 140mm Fan (2x), 180mm Fan (2x)
Case Fan Support Side
120mm Fan (2x), 140mm Fan (2x)
Case Fan Support Front
120mm Fan (3x), 140mm Fan (3x)
Max Number Of Fans
9
120 Mm Fans
9
140 Mm Fans
8
180 Mm Fans
2
Features
Housing Feedthrough
No
Internal Dimensions
Max Cooler Height
185 mm
Max Gpu Length
413 mm
Max Psu Length Depth
290 mm
I/O, Bays & Expansion
Front Side Top Panel I O
1 x Headphone Out
1 x Mic In
1 x Power Button
2 x USB 3.0
1 x USB 3.1 Gen2 Type-C
Drive Bays
2 x 2.5" Internal
2 x 3.5" / 1x 2.5"
Standard Expansion Slots
7
Vertical Expansion Slots
-
LED Lighting Functionality
Led Lighting
No
Led Lighting Emitters
-
Led Lighting Colour
-
Led Lighting Support Control
-
Lighting
Lighting Rgb
No
Liquid Cooling Support
Front Radiator Compatibility
-
Top Radiator Compatibility
1 x 280/360mm
1 x 360/420mm
Bottom Radiator Compatibility
-
Rear Radiator Compatibility
1 x 120/140mm
Side Radiator Compatibility
-
Materials
Materials
Plastic, Steel, Wood
Motherboard Support
Compatible Motherboard Formats
E-ATX, ATX, Micro-ATX, Mini-ITX
Max Motherboard Format
E-ATX
Mounting
Case Vesa Mountable
No
Internal Monitor Mount
No
Power Supply
Psu Included
No
Psu Format
ATX
Power Supply Position
rear bottom
Power Supply Compatibility
Psu Wattage If Included
-
Psu 80 Rating If Included
-
Psu Support
ATX
Psu Mounting Location
Bottom Mount, Rear
Max Psu Length
1 HDD Tray: 290 mm max / 2 HDD Tray: 175 mm max mm
Radiator Support
Radiator Aio Support Rear
120mm Radiator, 140mm Radiator
Max Radiator Compatibility
1x Single (140 mm), 1x Triple (360 mm), 1x Triple (420 mm)
Radiator Aio Support Front
360mm Radiator, 420mm Radiator
Radiator Aio Support Top
280mm Radiator, 360mm Radiator
Side Panels
Window S
No
Window Configuration
-
Window Construction
-
Best indexed price
£164.99GBP
Indexed 25 May 2026 — verify at retailer
