ASUS ZenScreen MB17AHG
MonitorsAsus

ASUS ZenScreen MB17AHG

Price TBC

Compatibility Data

Monitor Resolution888x214
Monitor Refresh Rate Hz144
Monitor Panel TypeIPS
Monitor Aspect Ratio16:9
Monitor Response Time Ms5
Monitor CurvedNo
Model: 22567

Technical Specifications17 specs

General

Model
ASUS ZenScreen MB17AHG
Display
  • Panel Size (inch) : 17.3
  • Pixels Per Inch (PPI) : 127
  • Aspect Ratio : 16:9
  • Display Viewing Area (H x V) : 381.888 x 214.812 mm
  • Display Surface : Anti-Glare
  • Backlight Type : LED
  • Panel Type : IPS
  • Viewing Angle (CR≧10, H/V) : 178°/ 178°
  • Pixel Pitch : 0.199mm
  • Resolution : 1920x1080
  • Color Space (sRGB) : 100%
  • Brightness (Typ.) : 300cd/㎡
  • Contrast Ratio (Typ.) : 800:1
  • Display Colors : 16.7M
  • Response Time : 5ms(GTG)
  • Refresh Rate (Max) : 144Hz
  • Flicker-free : Yes
Features
  • Trace Free Technology : Yes
  • SPLENDID Technology : Yes
  • Color Temp. Selection : Yes (4 modes)
  • Auto Rotation:Yes, supported by DisplayWidget Center
  • GamePlus : Yes
  • QuickFit : Yes (Photo/Alighment Grid)
  • HDCP : Yes, 2.2
  • VRR Technology : Yes (Adaptive-Sync)
  • DisplayWidget : Yes, DisplayWidget Center
  • Low Blue Light : Yes
Audio
Speaker : No
I O Ports
  • USB-C x 2 (DP Alt Mode)
  • HDMI(v1.4) x 1
  • Earphone Jack : Yes
Signal Frequency
  • Digital Signal Frequency : HDMI: 30KHz~180KHz(H)/60Hz ~144Hz (V)
  • USB-C: 180KHz(H)/60Hz ~144Hz (V)
Power Consumption
  • Power Consumption : <18W
  • Power Saving Mode : <0.5W
  • Power Off Mode : <0.5W
  • Voltage : 100-240V, 50/60Hz
Mechanical Design
  • Height Adjustment : No
  • 1/4" Tripod Socket : Yes
Dimensions Esti
  • Phys. Dimension (W x H x D) : 38.99 x 24.91 x 0.70 cm (15.35" x 9.81" x 0.28")
  • Box Dimension (W x H x D) : 47.30 x 32.30 x 11.90 cm (18.62" x 12.72" x 4.69")
Weight Esti
  • Net Weight : 1.29 kg (2.84 lbs)
  • Gross Weight : 3.75 kg (8.27 lbs)
Accessories Vary By Regions
  • ZenScreen sleeve
  • Warranty Card
  • USB-C cable
  • Quick start guide
  • Power adapter
  • HDMI cable
Operation Temperature Humidity
  • Operation Temperature : 5~35℃
  • Operation Humidity : 20-90% RH
Certificate
  • AMD FreeSync Premium
  • TÜV Low Blue Light
  • TÜV Flicker-free

Physical Dimensions

Length Mm
389.9
Width Mm
249.1
Height Mm
7
Weight G
1290
