ASUS ROG STRIX B250G GAMING
Quick Specs
ChipsetIntel® B365
MemoryDDR4
Form FactorATX
M.2 Slots2
About this motherboards
ROG Strix B250G Gaming mATX gaming motherboard features katana-inspired gaming aesthetics, Intel Gigabit LAN, dual M.2 and SupremeFX S1220A audio codec for a superior sound quality.
Technical Specifications23 specs
Physical Dimensions
Length Mm
304.8
Width Mm
243.8
Height Mm
774.7
Technical Specifications
Cpu
- Intel® Socket 11519th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
- Supports Intel® 14nm CPU
- * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
Chipset
Intel® B365
Memory
- 4 x DIMM, Max. 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory
- ** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.
- Supports Intel® Extreme Memory Profile (XMP)
- Dual Channel Memory Architecture
- * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
Graphic
- - Supports HDMI with max. resolution 4096 x 2160 @ 24Hz
- - Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz *1
- Multi-VGA output support : HDMI/DVI-D/DisplayPort ports
- Integrated Graphics Processor- Intel® HD Graphics support
- - Supports DVI-D with max. resolution 1920 x 1200 @ 60Hz
Multi Gpu Support
Supports AMD 2-Way CrossFireX Technology
Expansion Slots
- 8th Generation Intel® Core™ Processor
- 1 x PCIe 3.0/2.0 x16 (x4 mode) *2
- 3 x PCIe 3.0/2.0 x1 *3
- 1 x PCIe 3.0/2.0 x16 (x16 mode)
Storage
- 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)*4
- Intel® Rapid Storage Technology supports
- 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
- 6 x SATA 6Gb/s port(s)
- Intel® B365 Chipset :
- Intel® Optane™ Memory Ready
Lan
- Intel® I219V, 1 x Gigabit LAN Controller(s), Dual interconnect between the Integrated Media Access Controller (MAC) and Physical Layer (PHY)
- ROG GameFirst V Technology
- Anti-surge LANGuard
Audio
- ROG SupremeFX8-Channel High Definition Audio CODEC S1220A
- - Dual Headphone Amplifiers
- - Supports up to 32-Bit/192kHz playback *6
- - Impedance sense for front and rear headphone outputs
- - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
- - High quality120dBSNR stereo playback outputand113dBSNR recording input
- - SupremeFX Shielding Technology
- - Sonic Radar III
- - Sonic Studio III + Sonic Studio Link
- Audio Feature :
- - Optical S/PDIF out port(s) at back panel
Usb Ports
- 2 x USB 3.1 Gen 2 port(s) (2 at back panel, red)
- 4 x USB 3.1 Gen 2 port(s) (2 at back panel, , 1 x Type-A+1 x Type-C)
- 8 x USB 2.0 port(s) (4 at back panel, , 4 at mid-board)
- Intel® B365 Chipset :
Overclocking Features
- ROG CPU-Z
- Pre-mounted I/O Shield
- Overwolf
- ROG Aura
- ROG Exclusive Software
- - RAMCache III
- - GameFirst V
Special Features
- - ESD Guards on LAN, Audio, KBMS and USB3.1/3.0/2.0 ports
- - 3D printing friendly
- Digi+VRM
- - Aura Lighting Effects Synchronization with compatible ASUS ROG devices
- Gamer´s Guardian:
- - DRAM Overcurrent Protection
- - Stainless Steel Back I/O
- Gaming Aesthetics :
- - AURA-RGB Lighting
- Fan Xpert4
- - Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors selection for optimized system cooling control
- - Highly Durable components
- - SafeSlot
- AURA :
- - Aura Lighting Control
- - Aura RGB Strip Headers
- ASUS Exclusive Features :
- - AI Suite 3
- - Ai Charger
- - Armoury Crate
- ASUS EZ DIY :
- - ASUS CrashFree BIOS 3
- - ASUS EZ Flash 3
- ASUS Q-Design :
- - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- - ASUS Q-Slot
- - ASUS Q-DIMM
Back I O Ports
- 1 x USB 3.1 Gen 2 (red)Type-A
- 2 x USB 3.1 Gen 1 (black) Type-C
- 4 x USB 2.0
- 1 x PS/2 keyboard/mouse combo port(s)
- 1 x DVI-D
- 1 x DisplayPort
- 1 x HDMI
- 1 x LAN (RJ45) port(s)
- 1 x Optical S/PDIF out
- 5 x Audio jack(s)
Internal I O
- 1 x Aura RGB Strip Header(s)
- 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
- 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode)
- 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
- 1 x M.2_FAN connector
- 1 x 5-pin EXT_FAN(Extension Fan) connector
- 1 x 14-1 pin TPM connector
- 2 x 3D Mount screw port(s)
- 1 x AAFP connector
- 2 x Chassis Fan connector(s)
- 1 x Thermal sensor connector(s)
- 6 x SATA 6Gb/s connector(s)
- 1 x CPU Fan connector(s)
- 1 x CPU OPT Fan connector(s)
- 1 x AIO_PUMP connector
- 1 x 24-pin EATX Power connector(s)
- 1 x 8-pin ATX 12V Power connector(s)
- 1 x System panel(s)
- 1 x Clear CMOS jumper(s)
- 1 x COM port header
Accessories
- 1 x CABLE TIE BLACK
- 1 x ROG Door Hanger(s)
- 1 x 3D printing mount package
- 1 x ROG Strix stickers
- 1 x Extension Cable for RGB strips (80 cm)
- 4 x SATA 6Gb/s cable(s)
- User´s manual
- 1 x M.2 Screw Package
- 1 x Supporting DVD
Bios
1 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, Secure Erase, User Profile, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, , F4 AURA ON/OFF and F9 Search
Manageability
WOL, WOR, PXE
Operating System
Windows® 10 64-bit
Form Factor
- 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
- ATX Form Factor
Note
*1 DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain up to 3 displays.*2 The PCIEX16_2 slot shares bandwidth with PCIEX1_1 and PCIEX1_2 slots. When PCIEX1_1 and PCIEX1_2 slots are occupied, PCIEX16_2 slot runs at x2 mode. *3 The M.2_1 socket shares bandwidth with PCIEX1_4 *4 The M.2_1 socket shares bandwidth with SATA6G_2 port when using M.2 SATA mode device. Adjust BIOS settings to use X2 mode (PCIE only). The M.2_1 socket shares bandwidth with PCIEX1_4 *5 The M.2_2 socket supports Intel® Optane™ Technology. Intel® Optane™ Technology only supported when using 8th Generation Intel® Processors. Before using Intel® Optane™ memory modules, ensure that you have updated your motherboard drivers and BIOS to the latest version from ASUS support website.*6 Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.
