Silverstone SST-DA1650-G 80 PLUS Gold 1650W fully modular ATX power supply
MPN: SST-DA1650-G
Key specifications
Wattage1650 W
Form factor2U
ModularUnknown
EfficiencyUnknown
Depth60.0 mm
Best indexed price
Price unavailable
Retailer offers
Amazon UKProduct link
Find on AmazoneBay UKSearch link
Search eBayMore retailers coming
We only list a retailer once we hold verified offer data for it. No placeholder prices, ever.
Indexed prices are snapshots, not live quotes. Confirm price, stock and delivery on the retailer's site — checkout completes there.
We may earn a commission from these links. How it works
Fit check
Add this to your build in the PC Builder to automatically check dimensions, sockets, and power draw.
Related Products
Full Specifications42 fields
Additional Information
Model Number
SST-DA1650-G
Gtin
4710007229897
Design
Product Colour
Black
Fan Diameter
13.5 cm
Number Of Fans
1 fan(s)
Operational conditions
Operating Temperature T T
0 - 50 °C
Performance
80 Plus Certification
80 PLUS
Purpose
PC/Server
Power Supply Unit Psu Form Factor
2U
Noise Level
36 dB
Bearing Technology
FDB
Mean Time Between Failures Mtbf
100000 h
Ports & interfaces
Motherboard Power Connector
20-pin ATX
Motherboard Power Cable Length
60 cm
Number Of Sata Power Connectors
16
Peripheral Molex Power Connectors 4 Pin
6
Pci Express Power Connectors 6 Pin
12
Floppy Disk Drive Connector
Yes
Pci Express Connector
Yes
Cabling Type
Fully-Modular
Power
Total Power
1650 W
Ac Input Voltage
90 - 264 V
Ac Input Frequency
43 - 63 Hz
Power Factor
0.9
Power Factor Correction Pfc Type
Active
Combined Power 3 3v
130 W
Combined Power 12v
1650 W
Combined Power 5v
130 W
Max Output Current 3 3v
25 A
Max Output Current 12v
137.5 A
Max Output Current 5v
25 A
Max Output Current 12v
0.3 A
Max Output Current 5vsb
3 A
Efficiency
90%
Power Protection Features
Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Weight & dimensions
Width
150 mm
Depth
180 mm
Height
86 mm
Weight
2.09 kg
