Silverstone SST-DA1650-G 80 PLUS Gold 1650W fully modular ATX power supply
£269.99
Model: SST-DA1650-G
Technical Specifications42 specs
Additional Information
Model Number
SST-DA1650-G
Gtin
4710007229897
Design
Product Colour
Black
Fan Diameter
13.5 cm
Number Of Fans
1 fan(s)
Operational conditions
Operating Temperature T T
0 - 50 °C
Performance
80 Plus Certification
80 PLUS
Purpose
PC/Server
Power Supply Unit Psu Form Factor
2U
Noise Level
36 dB
Bearing Technology
FDB
Mean Time Between Failures Mtbf
100000 h
Ports & interfaces
Motherboard Power Connector
20-pin ATX
Motherboard Power Cable Length
60 cm
Number Of Sata Power Connectors
16
Peripheral Molex Power Connectors 4 Pin
6
Pci Express Power Connectors 6 Pin
12
Floppy Disk Drive Connector
Yes
Pci Express Connector
Yes
Cabling Type
Fully-Modular
Power
Total Power
1650 W
Ac Input Voltage
90 - 264 V
Ac Input Frequency
43 - 63 Hz
Power Factor
0.9
Power Factor Correction Pfc Type
Active
Combined Power 3 3v
130 W
Combined Power 12v
1650 W
Combined Power 5v
130 W
Max Output Current 3 3v
25 A
Max Output Current 12v
137.5 A
Max Output Current 5v
25 A
Max Output Current 12v
0.3 A
Max Output Current 5vsb
3 A
Efficiency
90%
Power Protection Features
Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Weight & dimensions
Width
150 mm
Depth
180 mm
Height
86 mm
Weight
2.09 kg
