Phanteks XT Pro ATX Case Tempered Glass Window, Black
CasesPhanteks

Phanteks XT Pro ATX Case Tempered Glass Window, Black

MPN: PH-XT523P1_BK01

Key specifications

Max GPU415.0 mm
Max Cooler184.0 mm
Max PSU270.0 mm
Form factorUnknown
Best indexed price
£95.79GBP
Indexed 19 Mar 2026 — verify at retailer. How we get prices

Retailer offers

eBay UK£95.79
Indexed 19 Mar 2026New · seller katomixshop
Check price at eBay
Amazon UKProduct link
Find on Amazon
More retailers coming

We only list a retailer once we hold verified offer data for it. No placeholder prices, ever.

Indexed prices are snapshots, not live quotes. Confirm price, stock and delivery on the retailer's site — checkout completes there.

We may earn a commission from these links. How it works

Fit check

Supports up to 415.0mm GPU clearance.

Supports up to 184.0mm CPU cooler height.

Check against your build

Related Products

Fractal Design Meshify 3 XL Ambience Pro RGB White TG Clear Tint Case
Fractal Design

Meshify 3 XL Ambience Pro RGB White TG Clear Tint Case

No price yet
Find on AmazonSearch eBay
CiT Impact Black Mid Tower PC Gaming Case
CIT

Impact Black Mid Tower PC Gaming Case

No price yet
Find on AmazonSearch eBay
SSUPD Meshroom S - Push Pin Mesh Side Panel - Fossil Grey
SSUPD

Meshroom S - Push Pin Mesh Side Panel - Fossil Grey

No price yet
Find on AmazonSearch eBay
Raijintek Metis Evo ALS Mini-ITX Case - White
Raijintek

Metis Evo ALS Mini-ITX Case - White

No price yet
Find on AmazonSearch eBay

Full Specifications69 fields

Additional Contents

Fans Included
Yes
Included Fans
1x 120 mm

Additional Information

Model Number
PH-XT523P1_BK01
Gtin
0886523303091

Back Connect

Back Connect
Yes
Back Connect Compatibility
ASUS BTF, MSI Project Zero, Gigabyte Project Stealth

Cable Specifications

Riser Cable Included
No

Case

Case Type
Mid Tower

Case Features

I O Position
Top
Side Panel
with window
Vertical Gpu Mount
No
Adjustable Vertical Gpu Bracket
No
Front Door
No
Cable Management
Yes
Filters Included
Yes
Filter Position
Top
Noise Dampening
No
Mainboard Slide Tray
No
Transport System
No

Colour

Primary Colour
Black

Compliance

Compliance Documents
Phanteks Case Compliance and Safety

Dimensions

Length Depth
450 mm
Width
230 mm
Height
500 mm
Weight
7.55 kg

Display

Display Included
No

Drive Bays

Max 2 5 Inch Drives
5
Max 3 5 Inch Drives
2
Max 5 25 Inch Drives
0
2 5 Inch Internal Drive Bay
5
3 5 Inch Internal Drive Bay
2
Hot Swap Drive Bays
No

Expansion Slots

Expansion Slots Pci Slots
7

External Ports

Front I O Usb Type C Ports Total
1
Front I O Usb Type A Ports Total
1
Usb 3 1 External Type C
1
Usb 3 0 External Type A
1
Audio Outputs Inputs
1x output / input comb. (3.5 mm jack, 4-pin, TRRS)
Card Reader
No

Fan Header

Fan Controller Fan Hub
No

Fan Support

Case Fan Support Bottom
120mm Fan (3x)
Case Fan Support Front
120mm Fan (3x), 140mm Fan (3x)
Case Fan Support Rear
120mm Fan (1x), 140mm Fan (1x)
Case Fan Support Top
120mm Fan (3x), 140mm Fan (2x)
Max Number Of Fans
10
120 Mm Fans
10
140 Mm Fans
6

Features

Housing Feedthrough
No

Internal Dimensions

Max Cooler Height
184 mm
Max Gpu Length
415 mm
Max Gpu Width
184 mm
Max Psu Length Depth
270 mm

Lighting

Lighting Rgb
No

Materials

Materials
ABS, Steel, Tempered Glass

Motherboard Support

Compatible Motherboard Formats
E-ATX, ATX, Micro-ATX, Mini-ITX
Max Motherboard Format
E-ATX

Mounting

Internal Monitor Mount
No
Case Vesa Mountable
No

Power Supply

Psu Included
No
Psu Format
ATX
Power Supply Position
rear bottom

Product Series

Product Series Family
XT Pro

Radiator Support

Max Radiator Compatibility
1x Single (120 mm), 1x Dual (240 mm), 1x Triple (360 mm)
Radiator Aio Support Front
240mm Radiator
Radiator Aio Support Rear
120mm Radiator
Radiator Aio Support Top
360mm Radiator
