CasesNZXT
NZXT H5 Elite White Mid Tower Tempered Glass PC Gaming Case
£99.99
Model: CC-H51EW-01
Technical Specifications41 specs
Additional Information
Model Number
CC-H51EW-01
Gtin
5056547202372
Chassis Physical Specifications
Colour
White
Chassis Construction Materials
SGCC / Tempered Glass
Dimensions
227 x 464 x 446 (WxHxD mm)
Weight
8.1 kg (Approx)
Package Type
-
Please Note
-
Clearances
Max Cooler Height
165 mm
Max Gpu Length
365 mm
Cable Routing Space
23 mm
Core Chassis Specifications
Edition
H5 Elite
Case Form Factor
Mid Tower
Motherboard Form Factor
ATX
E-ATX (272mm Wide Max.)
MicroATX
Mini-ITX
Back Connect Compatible
No
Fans & Filters
Fan Bays
2 x 120/140mm
4 x 120mm
Fans Included
1 x 120mm
2 x 140mm w/ Addressable RGB LEDs
Fan Controller Hub
-
Dust Filters
Bottom
PSU
Top
I/O, Bays & Expansion
Front Side Top Panel I O
1 x Headphone/Mic Combo
1 x USB 3.2 Gen1 Type-A
1 x USB 3.2 Gen2 Type-C
Drive Bays
1 x 2.5" Internal
1 x 2.5"/ 3.5" Internal
Standard Expansion Slots
7
Vertical Expansion Slots
-
LED Lighting Functionality
Led Lighting
Yes
Led Lighting Emitters
Included Addressable LED Fan/s
Led Lighting Colour
RGB
Led Lighting Support Control
-
Liquid Cooling Support
Front Radiator Compatibility
1 x 120/140/240/280mm
Top Radiator Compatibility
1 x 120/240mm
Bottom Radiator Compatibility
-
Rear Radiator Compatibility
1 x 120mm
Side Radiator Compatibility
-
Power Supply Compatibility
Psu Included
No
Psu Wattage If Included
-
Psu 80 Rating If Included
-
Psu Support
ATX
Psu Mounting Location
Bottom Mount, Rear
Max Psu Length
-
Side Panels
Window S
Yes
Window Configuration
1 x Front
1 x Main Side
Window Construction
Tempered Glass
