CasesNZXT
NZXT H3 Flow Micro ATX Airflow Case - Black
MPN: CC-H31FB-01
Key specifications
Max GPU377.0 mm
Max Cooler170.0 mm
Max PSU185.0 mm
Form factorUnknown
Full Specifications63 fields
Additional Contents
Fans Included
Yes
Included Fans
1x 120 mm
Additional Information
Model Number
CC-H31FB-01
Gtin
5056547207988
Back Connect
Back Connect
Yes
Back Connect Compatibility
ASUS BTF, MSI Project Zero
Cable Specifications
Riser Cable Included
No
Case
Case Type
Mid Tower
Case Features
I O Position
Top
Side Panel
with window
Vertical Gpu Mount
No
Adjustable Vertical Gpu Bracket
No
Front Door
No
Cable Management
Yes
Filters Included
Yes
Noise Dampening
No
Mainboard Slide Tray
No
Transport System
No
Colour
Primary Colour
Black
Connectivity
Card Reader
No
Dimensions
Length Depth
389 mm
Width
255 mm
Height
400 mm
Weight
4.8 kg
Display
Display Included
No
Drive Bays
Max 2 5 Inch Drives
3
Max 3 5 Inch Drives
1
Max 5 25 Inch Drives
0
Hot Swap Drive Bays
No
Expansion Slots
Expansion Slots Pci Slots
4
External Ports
Front I O Usb Type C Ports Total
1
Front I O Usb Type A Ports Total
1
Usb 3 2 External Type C
1
Usb 3 0 External Type A
1
Fan Header
Fan Controller Fan Hub
No
Fan Support
Case Fan Support Top
120mm Fan (2x), 140mm Fan (2x)
Max Number Of Fans
7
Case Fan Support Front
120mm Fan (2x), 140mm Fan (2x)
Case Fan Support Bottom
120mm Fan (2x)
Case Fan Support Rear
120mm Fan (1x)
120 Mm Fans
7
140 Mm Fans
4
Features
Housing Feedthrough
No
Internal Dimensions
Max Cooler Height
170 mm
Max Gpu Length
377 mm
Max Psu Length Depth
185 mm
Lighting
Lighting Rgb
No
Materials
Materials
Tempered Glass, SGCC (Steel)
Motherboard Support
Compatible Motherboard Formats
Micro-ATX, Mini-ITX
Max Motherboard Format
Micro-ATX
Mounting
Case Vesa Mountable
No
Internal Monitor Mount
No
Power Supply
Psu Included
No
Psu Format
ATX
Power Supply Position
rear bottom
Radiator Support
Max Radiator Compatibility
1x Dual (240 mm), 1x Dual (280 mm)
Radiator Aio Support Front
280mm Radiator
Radiator Aio Support Rear
120mm Radiator
Radiator Aio Support Top
240mm Radiator
