Technical Specifications47 specs
Additional Contents
Included Fans
2x 120 mm
Additional Information
Model Number
NH-U12A
Gtin
9010018000160
Colour
Primary Colour
Brown
Fan Main Colour Frame
Brown
Fan Main Colour Rotor
Brown
Cooler Specifications
Edition
NH-U12A
Cooler Form Factor
Single Tower
Heatpipes
7
Cooler Features
Adjustable Height Fan
Aluminium Fins
Low-Noise Cable
Nickel-Plated Copper Base
Nickel-Plated Copper Heatpipes
Push-Pull Operation
Socket Compatibility
1150
1151
1155
1156
1700
1851
2011
2011-3
2066
AM2
AM2+
AM3
AM3+
AM4
FM1
FM2
FM2+
Additional Fans Possible
No
Max Tdp
-
Ventilation Type
active
Number Of Heatpipes
7
Heatpipe Diameter
6 mm
CPU
Socket
AM2+, 1150, 1151, 1155, 1156, 2011, 2066, AM2, AM3+, AM4, FM1, FM2+, AM5, 1851
Dimensions
Length Depth
112 mm
Width
125 mm
Height
158 mm
Weight
1220 g
Dimensions & Weight
Heatsink Radiator Dimensions
125 x 158 x 58 mm (WxHxD)
Total Dimensions
125 x 158 x 112 mm (WxHxD)
Fan Specifications
Included Fan Configuration
2 x 120mm
Fan Edition
Noctua NF-A12x25 PWM
Pwm Fan
Yes
Fan Bearing Type
SSO2
Fan Colour
Beige/Brown
Led Lighting
N/A
Fan Pump Connectors
1 x 4-pin
Max Fan Speed
2000 rpm
Max Fan Airflow
60 CFM
Max Air Pressure
2.34 mm H²O
Max Fan Rpm
2000 rpm
Max Sound Level
22.6 dBA
Max Single Fan Airflow
102.1 m³/h
Max Static Pressure
2.34 mmH2O
Internal Ports
Fan Connectors
4 Pin (PWM)
Lighting
Lighting Rgb
No
Materials
Included Tim Thermal Interface Material
NT-H1 High-Grade Thermal Compound (Included)
Base Plate Material
Nickel-plated copper
Heat Sink Material
Aluminium (nickel-plated)
Noise
Max Single Fan Noise Db A
22.6 dB(A)
Type
Cpu Cooler Type
Single Tower
General
Cooler Materials
Aluminium / Nickel Plated / Copper
