MSI MAG FORGE M100R ARGB Micro-ATX PC Gaming Case
MPN: MAG FORGE M100R
Key specifications
Max GPU300 mm
Max Cooler160 mm
Max PSUUnknown
Form factormATX
Full Specifications41 fields
Additional Information
Model Number
MAG FORGE M100R
Gtin
4719072932220
Chassis Physical Specifications
Colour
Black
Chassis Construction Materials
-
Dimensions
200 x 423 x 388 (WxHxD mm)
Weight
-
Package Type
-
Please Note
-
Clearances
Max Cooler Height
160 mm
Max Gpu Length
300 mm
Cable Routing Space
-
Core Chassis Specifications
Edition
MAG FORGE M100R
Case Form Factor
MicroATX
Motherboard Form Factor
MicroATX
Mini-ITX
Back Connect Compatible
No
Fans & Filters
Fan Bays
6 x 120mm
Fans Included
4 x 120mm w/ Addressable RGB LEDs
Fan Controller Hub
-
Dust Filters
Top
I/O, Bays & Expansion
Front Side Top Panel I O
1 x Headphone Out
1 x Mic In
2 x USB 2.0
1 x USB 3.2 Gen1 Type-A
Drive Bays
2 x 2.5" Internal
1 x 2.5"/ 3.5" Internal (Accessible)
1 x 3.5" Internal
Standard Expansion Slots
4
Vertical Expansion Slots
-
LED Lighting Functionality
Led Lighting
Yes
Led Lighting Emitters
Included Addressable LED Fan/s
Led Lighting Colour
RGB
Led Lighting Support Control
Compatible with MSI Mystic Light Sync
Liquid Cooling Support
Front Radiator Compatibility
1 x 120/240mm
Top Radiator Compatibility
1 x 120/240mm
Bottom Radiator Compatibility
-
Rear Radiator Compatibility
1 x 120mm
Side Radiator Compatibility
-
Power Supply Compatibility
Psu Included
No
Psu Wattage If Included
-
Psu 80 Rating If Included
-
Psu Support
ATX
Psu Mounting Location
Bottom Mount, Rear
Max Psu Length
300 (Without HDD Tray Installed) mm
Side Panels
Window S
Yes
Window Configuration
1 x Main Side
Window Construction
Tempered Glass
Best indexed price
£64.99GBP
Indexed 24 May 2026 — verify at retailer
