Technical Specifications70 specs
Additional Contents
Fans Included
Yes
Included Fans
4x 120 mm
Additional Information
Model Number
XR Wood (B)
Gtin
4710562749434
Back Connect
Back Connect
No
Cable Specifications
Riser Cable Included
No
Case
Case Type
Mid Tower
Case Features
I O Position
Top
Side Panel
with window
Vertical Gpu Mount
No
Adjustable Vertical Gpu Bracket
No
Front Door
No
Cable Management
Yes
Filters Included
Yes
Filter Position
Top, Bottom, Side, Front
Noise Dampening
No
Mainboard Slide Tray
No
Transport System
No
Colour
Primary Colour
Black
Compliance
Compliance Documents
Montech Case Compliance and Safety
Connectivity
Card Reader
No
Dimensions
Length Depth
475 mm
Width
230 mm
Height
456 mm
Display
Display Included
No
Drive Bays
Max 2 5 Inch Drives
2
Max 3 5 Inch Drives
2
Max 5 25 Inch Drives
0
2 5 Inch Internal Drive Bay
2
3 5 Inch Internal Drive Bay
2
1x 3 5 1x 2 5 Inch Internal Drive Bays Combined
4
Hot Swap Drive Bays
No
Expansion Slots
Expansion Slots Pci Slots
7
External Ports
Front I O Usb Type C Ports Total
1
Front I O Usb Type A Ports Total
2
Usb 3 1 External Type C
1
Usb 3 0 External Type A
2
Audio Outputs Inputs
1x output + 1x input (3.5 mm jack, 3-pin, TRS)
Fan Header
Fan Controller Fan Hub
No
Fan Support
Max Number Of Fans
12
Case Fan Support Rear
120mm Fan (1x), 140mm Fan (1x)
Case Fan Support Side
120mm Fan (2x)
Case Fan Support Front
120mm Fan (3x), 140mm Fan (2x)
Case Fan Support Bottom
120mm Fan (3x)
Case Fan Support Top
120mm Fan (3x), 140mm Fan (2x)
120 Mm Fans
12
140 Mm Fans
5
Features
Housing Feedthrough
No
Internal Dimensions
Max Cooler Height
175 mm
Max Gpu Length
420 mm
Max Psu Length Depth
230 mm
Lighting
Lighting Rgb
Yes
Rgb Controller
No
Lighting Colour
RGB
Materials
Materials
Plastic, Aluminium, Tempered Glass, Wood
Motherboard Support
Compatible Motherboard Formats
ATX, Micro-ATX, Mini-ITX
Max Motherboard Format
ATX
Mounting
Case Vesa Mountable
No
Internal Monitor Mount
No
Power Supply
Psu Included
No
Psu Format
ATX
Power Supply Position
rear bottom
Radiator Support
Max Radiator Compatibility
2x Triple (360 mm)
Radiator Aio Support Front
120mm Radiator, 140mm Radiator, 240mm Radiator, 360mm Radiator
Radiator Aio Support Rear
120mm Radiator, 140mm Radiator
Radiator Aio Support Top
120mm Radiator, 140mm Radiator, 240mm Radiator, 360mm Radiator
