Technical Specifications69 specs
Additional Contents
Fans Included
No
Included Fans
None
Additional Information
Model Number
O11D MINI-X
Gtin
4718466009722
Back Connect
Back Connect
No
Cable Specifications
Riser Cable Included
No
Case
Case Type
Mid Tower
Case Features
I O Position
Top
Side Panel
with window
Vertical Gpu Mount
No
Adjustable Vertical Gpu Bracket
No
Front Door
No
Cable Management
Yes
Filters Included
Yes
Filter Position
Top, Bottom, Side
Noise Dampening
No
Mainboard Slide Tray
No
Remote Included
No
Transport System
No
Colour
Primary Colour
Black
Secondary Colour
Transparent
Compliance
Compliance Documents
Lian Li Case Compliance and Safety
Dimensions
Length Depth
420 mm
Width
269.5 mm
Height
380 mm
Weight
8.5 kg
Display
Display Included
No
Drive Bays
Max 2 5 Inch Drives
4
Max 3 5 Inch Drives
2
Max 5 25 Inch Drives
0
2 5 Inch Internal Drive Bay
2
1x 3 5 1x 2 5 Inch Internal Drive Bays Combined
2
Hot Swap Drive Bays
No
Expansion Slots
Expansion Slots Pci Slots
7
External Ports
Front I O Usb Type C Ports Total
1
Front I O Usb Type A Ports Total
2
Usb 3 1 External Type C
1
Usb 3 0 External Type A
2
Audio Outputs Inputs
1x output / input comb. (3.5 mm jack, 4-pin, TRRS)
Card Reader
No
Fan Header
Fan Controller Fan Hub
No
Fan Support
Case Fan Support Rear
120mm Fan (1x)
Case Fan Support Bottom
120mm Fan (3x), 140mm Fan (2x)
Case Fan Support Top
120mm Fan (3x), 140mm Fan (2x)
Case Fan Support Side
120mm Fan (2x), 140mm Fan (2x)
Max Number Of Fans
9
120 Mm Fans
9
140 Mm Fans
6
Features
Housing Feedthrough
No
Internal Dimensions
Max Cooler Height
170 mm
Max Gpu Length
395 mm
Max Psu Length Depth
165 mm
Lighting
Lighting Rgb
No
Materials
Materials
Aluminium, Steel, Tempered Glass
Motherboard Support
Compatible Motherboard Formats
E-ATX, ATX, Micro-ATX, Mini-ITX
Max Motherboard Format
E-ATX
Mounting
Internal Monitor Mount
No
Case Vesa Mountable
No
Power Supply
Psu Included
No
Psu Format
SFX-L, SFX
Power Supply Position
rear side / top
Product Series
Product Series Family
O11
Radiator Support
Max Radiator Compatibility
2x Triple (360 mm)
Radiator Aio Support Bottom
240mm Radiator, 280mm Radiator, 360mm Radiator
Radiator Aio Support Side
240mm Radiator, 280mm Radiator
Radiator Aio Support Top
240mm Radiator, 280mm Radiator, 360mm Radiator
