Graphics CardsGigabyte
Gigabyte NVIDIA GeForce RTX 2060 12GB WINDFORCE OC Turing Graphics Card
Quick Specs
ChipsetRTX 2060
VRAM12 GB
MemoryGDDR6
Length224 mm
Min PSU550 W
Model: GV-N2060WF2OC-12GD
Technical Specifications35 specs
Additional Information
Model Number
GV-N2060WF2OC-12GD
Gtin
4719331310509
Cooling
Included Backplate
Yes
Cores & Clocks
Cores
2176
Core Clock
1650 MHz
Boost Clock
1680 MHz
Ai Tops
-
I/O & Connectivity
Interface
PCIe 3.0 (x16)
Connectivity
3 x DisplayPort 1.4
1 x HDMI 2.0b
Key Specifications
Chipset
GeForce RTX 2060
Edition
RTX 2060 12GB Windforce OC
Manufacturing Process
-
Microarchitecture
Turing
Physical
Width
2.5 Slot
Low Profile Support
N/A
Dimensions
224 x 121 x 41 mm
Package Type
Retail
Power & Thermals
Graphics Card Power Connectors
1 x 8-pin PCIe
Tdp
-
Minimum Recommended Psu
550 W
Maximum Gpu Temperature
-
Ray
Tracing Real Time Ray Tracing
Yes
Tracing Nvidia Rt Cores
-
Tracing Nvidia Tensor Cores
-
Video Memory (VRAM)
Vram Size
12GB
Memory Type
GDDR6
Memory Clock
14000 MHz
Memory Bus
192 Bit
Visuals
Geforce Vr Ready
Yes
Multi Way Graphics Support
Not Supported
Microsoft Directx Support
12 API
Hdcp Ready
No
Max Concurrent Displays
4 Displays
Maximum Digital Resolution
7680x4320 (8K UHD)
General
Solution
Dual Fan (2)
