CasesFractal Design
Fractal North XL Charcoal Dark Tint Tempered Glass Mid Tower Case
MPN: FD-C-NOR1X-02
Key specifications
Max GPU360 mm
Max Cooler185 mm
Max PSU290 mm
Form factorMid Tower
Full Specifications41 fields
Additional Information
Model Number
FD-C-NOR1X-02
Gtin
7340172706540
Chassis Physical Specifications
Colour
Charcoal
Chassis Construction Materials
Steel / Tempered Glass
Dimensions
240 x 509 x 503 (WxHxD mm)
Weight
9.5 kg (Approx)
Package Type
-
Please Note
-
Clearances
Max Cooler Height
185 mm
Max Gpu Length
413 with front fan mounted / 380 with 420/360 mm front mounted Rad mm
Cable Routing Space
29 mm
Core Chassis Specifications
Edition
Fractal North XL - Charcoal Black TG
Case Form Factor
Mid Tower
Motherboard Form Factor
ATX
E-ATX (330 mm)
MicroATX
Mini-ITX
Back Connect Compatible
No
Fans & Filters
Fan Bays
7 x 120mm / 6x 140mm
Fans Included
3 x 140mm
Fan Controller Hub
-
Dust Filters
Front
PSU
I/O, Bays & Expansion
Front Side Top Panel I O
1 x Headphone Out
1 x Mic In
2 x USB 3.0
1 x USB 3.1 Gen2 Type-C
Drive Bays
2 x 2.5" Internal
2 x 2.5"/ 3.5" Internal
Standard Expansion Slots
7
Vertical Expansion Slots
-
LED Lighting Functionality
Led Lighting
No
Led Lighting Emitters
-
Led Lighting Colour
-
Led Lighting Support Control
-
Liquid Cooling Support
Front Radiator Compatibility
1 x 360/420mm
Top Radiator Compatibility
1 x 280/360mm
Bottom Radiator Compatibility
-
Rear Radiator Compatibility
1 x 120/140mm
Side Radiator Compatibility
-
Power Supply Compatibility
Psu Included
No
Psu Wattage If Included
-
Psu 80 Rating If Included
-
Psu Support
ATX
Psu Mounting Location
Bottom Mount, Rear
Max Psu Length
1 HDD Tray: 290 mm max / 2 HDD Tray: 175 mm max mm
Side Panels
Window S
Yes
Window Configuration
1 x Main Side
Window Construction
Tempered Glass (Tinted)
Best indexed price
£174.99GBP
Indexed 24 May 2026 — verify at retailer
