Technical Specifications52 specs
Additional Information
Model Number
BK035
Gtin
4260052190739
Design
Product Colour
Black
Base Plate Material
Copper
Number Of Fans
1 fan(s)
Fins Material
Aluminium
Number Of Heat Pipes
6
Fan Connector
4-pin
Other features
Thermal Grease
Yes
Packaging content
Mounting Kit
Yes
Screws Included
Yes
Number Of Screws
8
Number Of Nuts
4
Installation Instruction
Yes
Cpu Bracket S
Yes
Performance
Suitable Location
Processor
Type
Air cooler
Fan Diameter
12 cm
Supported Processor Sockets
LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1200 (Socket H5), LGA 1700, LGA 1851, Socket AM4, Socket AM5
Rotational Speed Max
2100 RPM
Noise Level Low Speed
11.9 dB
Noise Level High Speed
29.8 dB
Maximum Airflow
55 cfm
Airflow
93.5 m³/h
Maximum Air Pressure
2.73 mmH2O
Pulse Width Modulation Pwm Support
Yes
Bearing Type
Fluid Dynamic Bearing (FDB)
Quantity Per Pack
1 pc(s)
Fan S Mean Time To Failure Mttf
300000 h
Power
Rated Voltage
12 V
Fan Power Consumption
2.4 W
Maximum Current
0.2 A
Thermal Design Power Tdp
210 W
Fan Current
0.1 A
Technical details
Warranty Period
3 year(s)
Compliance Certificates
CE, RoHS, TÜV mark, UKCA, UL, WEEE
Weight & dimensions
Width
136 mm
Radiator Width
13.6 cm
Radiator Depth
7.6 cm
Radiator Height
16.1 cm
Depth
101 mm
Height
161 mm
Weight
1.03 kg
Fan Dimensions W X D X H
120 x 120 x 25 mm
Heat Pipes Diameter
6 mm
Cable Length
0.22 m
Package Width
146 mm
Package Depth
198 mm
Package Height
224 mm
Package Weight
1.5 kg
