ASUS ZenScreen Touch MB16AMTR — Monitor | Build My PC
Home
Parts
Monitors
ASUS ZenScreen Touch MB16AMTR
Monitors
Asus
ASUS ZenScreen Touch MB16AMTR
Check Price
Quick Specs
Resolution
1920x1080
Refresh
60 Hz
Panel
IPS
Response
5 ms
Model:
25254
About this monitors
ASUS ZenScreen Touch MB16AMTR portable monitor: 15.6-inch FHD IPS, 10-point touch, built-in battery, USB-C, mini-HDMI, and versatile kickstand for multitasking.
Technical Specifications
18 specs
General
Model
ASUS ZenScreen Touch MB16AMTR
Display
Panel Size (inch) : 15.6
Aspect Ratio : 16:9
Display Viewing Area (H x V) : 344.16 x 193.59 mm
Display Surface : Anti-Glare
Backlight Type : LED
Panel Type : IPS
Viewing Angle (CR≧10, H/V) : 170°/ 170°
Pixel Pitch : 0.179mm
Resolution : 1920x1080
Brightness (Typ.) : 250cd/㎡
Contrast Ratio (Typ.) : 700:1
Display Colors : 260K
Response Time : 5ms(GTG)
Refresh Rate (Max) : 60Hz
Touch : Yes, Projective Capacitive 10-point Touch
Flicker-free : Yes
Features
SPLENDID Technology : Yes
Color Temp. Selection : Yes (4 modes)
Auto Rotation:Yes, supported by DisplayWidget Center
QuickFit : Yes (Photo/Alighment Grid)
HDCP : Yes
DisplayWidget : Yes, DisplayWidget Center
Low Blue Light : Yes
Audio
Speaker : Yes(1Wx2)
I O Ports
USB-C x 2 (DP Alt Mode & USB 3.2 x1 + DC In x1)
Mini HDMI x 1
Earphone Jack : Yes
USB-C Power Delivery : 10W
USB 3.2 (Signal) : x 1
Signal Frequency
Digital Signal Frequency : HDMI: 24~83 KHz (H) / 50~61 Hz (V)
USB-C: 83~83 KHz (H) / 50~61 Hz (V)
Battery
Battery : 7800mAh
Power Consumption
Power Consumption : 10W
Power Saving Mode : <0.5W
Power Off Mode : <0.3W
Voltage : 100-240V, 50/60Hz
Mechanical Design
Tilt : Yes (+15° ~ +35°)
Height Adjustment : No
1/4" Tripod Socket : Yes
Dimensions Esti
Phys. Dimension (W x H x D) : 35.99 x 22.68 x 1.19 cm (14.17" x 8.93" x 0.47")
Phys. Dimension without Stand (W x H x D) : 35.99 x 22.68 x 1.19 cm (14.17" x 8.93" x 0.47")
Box Dimension (W x H x D) : 48.8 x 29.8 x 8.8 cm (19.21" x 11.73" x 3.46")
Weight Esti
Net Weight without Stand : 1.15 kg (2.54 lbs)
Gross Weight : 2.29 kg (5.05 lbs)
Accessories Vary By Regions
ZenScreen tripod hole cover
ZenScreen sleeve
Warranty Card
USB-C cable
USB Type-C to A adapter
Quick start guide
Power adapter
Mini HDMI to HDMI cable
Operation Temperature Humidity
Operation Temperature : 5~35℃
Operation Humidity : 20-90% RH
Certificate
TÜV Low Blue Light
TÜV Flicker-free
Physical Dimensions
Length Mm
359.9
Width Mm
226.8
Height Mm
11.9
Weight G
1150
