ASUS ZenScreen MB169CK
MonitorsAsus

ASUS ZenScreen MB169CK

Price TBC

Compatibility Data

Monitor Resolution1920x1080
Monitor Refresh Rate Hz60
Monitor Panel TypeIPS
Monitor Aspect Ratio16:9
Monitor Response Time Ms5
Monitor CurvedNo
Model: 30974

Technical Specifications17 specs

General

Model
ASUS ZenScreen MB169CK
Display
  • Panel Size (inch) : 15.6
  • Aspect Ratio : 16:9
  • Display Viewing Area (H x V) : 344.16 x 193.59mm
  • Display Surface : Anti-Glare
  • Backlight Type : LED
  • Panel Type : IPS
  • Viewing Angle (CR≧10, H/V) : 178°/ 178°
  • Pixel Pitch : 0.179mm
  • Resolution : 1920x1080
  • Brightness (Typ.) : 250cd/㎡
  • Contrast Ratio (Typ.) : 800:1
  • Display Colors : 262K
  • Response Time : 5ms(GTG)
  • Refresh Rate (Max) : 60Hz
  • Flicker-free : Yes
Features
  • Trace Free Technology : Yes
  • SPLENDID Technology : Yes
  • Color Temp. Selection : Yes (4 modes)
  • Auto Rotation:Yes, supported by DisplayWidget Center
  • QuickFit : Yes (Photo/Alighment Grid)
  • HDCP : Yes, 1.4
  • DisplayWidget : Yes, DisplayWidget Center
  • Low Blue Light : Yes
Audio
Speaker : No
I O Ports
  • USB-C x 2 (DP Alt Mode)
  • Mini HDMI x 1
Signal Frequency
  • Digital Signal Frequency : USB-C: 24~83KHZ (H) / 50~60Hz(V)
  • HDMI: 24~83KHZ (H) / 50~60Hz(V)
Power Consumption
  • Power Consumption : 7.64 W
  • Power Saving Mode : <0.5W
  • Power Off Mode : <0.3W
  • Voltage : 100-240V, 50/60Hz
Mechanical Design
  • Height Adjustment : No
  • 1/4" Tripod Socket : Yes
Dimensions Esti
  • Phys. Dimension without Stand (W x H x D) : 36.0 x 22.6 x 1.2 cm (14.17" x 8.90" x 0.47")
  • Box Dimension (W x H x D) : 43.4 x 29.0 x 7.6 cm (17.09" x 11.42" x 2.99")
Weight Esti
  • Net Weight without Stand : 0.78 kg (1.72 lbs)
  • Gross Weight : 1.70 kg (3.75 lbs)
Accessories Vary By Regions
  • ZenScreen sleeve
  • Warranty Card
  • USB-C cable
  • Quick start guide
  • Mini HDMI to HDMI cable
  • 360° kickstand
Certificate
  • FSC MIX
  • TÜV Low Blue Light
  • TÜV Flicker-free
  • Energy Star
Note
*Box weight may vary from regions

Physical Dimensions

Length Mm
360
Width Mm
226
Height Mm
12
Weight G
780
