ASUS ZenScreen Ink MB14AHD
Quick Specs
Resolution1920x1080
Refresh60 Hz
PanelIPS
Response5 ms
Model: 20770
About this monitors
14-inch FHD (1920 x 1080), IPS, 10-point touch, Stylus Pen, USB-C®, Micro HDMI, ergo kickstand, tripod socket, ASUS Flicker Free and Low Blue Light technologies. MPP 2.0 stylus with 4096-level pressure sensitivity and low latency for precise and exceptional writing experiences. Integrated stepless kickstand offers up to 150° of hinge movement.
Technical Specifications19 specs
General
Model
ZenScreen Ink MB14AHD
Display
- Panel Size (inch) : 14
- Aspect Ratio : 16:9
- Display Viewing Area (H x V) : 309.37 x 174.02 mm
- Display Surface : Glare
- Backlight Type : LED
- Panel Type : IPS
- Viewing Angle (CR≧10, H/V) : 170°/ 170°
- Pixel Pitch : 0.161mm
- Resolution : 1920x1080
- Brightness (Typ.) : 220cd/㎡
- Contrast Ratio (Typ.) : 800:1
- Display Colors : 262K
- Response Time : 5ms(GTG)
- Refresh Rate (Max) : 60Hz
- Touch : PCT + MPP2.0 Active Pen
- Protection Glass : Yes
- Flicker-free : Yes
Features
- Trace Free Technology : Yes
- SPLENDID Technology : Yes
- Color Temp. Selection : Yes (4 modes)
- GamePlus : Yes
- QuickFit : Yes
- HDCP : Yes
- DisplayWidget : Yes
- Low Blue Light : Yes
Audio
Speaker : No
I O Ports
- USB-C x 2 (DP Alt Mode)
- Micro HDMI x 1
- Earphone Jack : Yes
Signal Frequency
- Digital Signal Frequency : HDMI：24Khz~83KHz
- USB-C: 83KHz
- Analog Signal Frequency : NA
Battery
Battery : NA
Power Consumption
- Power Consumption : 8.21 W
- Power Saving Mode : <0.5W
- Power Off Mode : <0.3W
- Voltage : 100-240V, 50/60Hz
Mechanical Design
- Height Adjustment : No
- 1/4" Tripod Socket : Yes
Dimensions Esti
- Phys. Dimension without Stand (W x H x D) : 32.42 x 20.12 x 1.25 cm (12.76" x 7.92" x 0.49")
- Box Dimension (W x H x D) : 45.40 x 31.00 x 7.80 cm (17.87" x 12.20" x 3.07")
Weight Esti
- Net Weight without Stand : 0.87 kg (1.92 lbs)
- Gross Weight : 2.64 kg (5.82 lbs)
Accessories Vary By Regions
- ZenScreen sleeve
- Warranty Card
- USB-C cable
- USB Type-C to A adapter
- Quick start guide
- Power adapter
- Micro HDMI to HDMI cable
- ASUS Pen (MPP2.0)
Operation Temperature Humidity
- Operation Temperature : NA
- Operation Humidity : NA
Certificate
- TÜV Low Blue Light
- TÜV Flicker-free
Note
- * Battery goes with inbox stylus pen, please remember to remove isolation sheet in the stylus pen in the first use
- * Please be noted that the battery size/format for the stylus pen is AAAA
- * The warranty period of stylus pen is 12 months
Physical Dimensions
Length Mm
324.2
Width Mm
201.2
Height Mm
12.5
Weight G
870
