CasesAsus
Asus ROG Hyperion GR701 BTF Edition Full Tower E-ATX Case - Black
MPN: 90DC00F0-B39020
Key specifications
Max GPU460 mm
Max Cooler190 mm
Max PSU240 mm
Form factorFull Tower
Full Specifications92 fields
Additional Contents
Fans Included
Yes
Included Fans
4x 140 mm
Additional Information
Model Number
90DC00F0-B39020
Gtin
4711387483749
Back Connect
Back Connect
No
Cable Specifications
Riser Cable Included
No
Case
Case Type
Full Tower
Case Features
I O Position
Front
Side Panel
with window
Vertical Gpu Mount
Yes
Adjustable Vertical Gpu Bracket
No
Front Door
No
Cable Management
Yes
Filters Included
Yes
Noise Dampening
Yes
Mainboard Slide Tray
No
Transport System
Yes
Chassis Physical Specifications
Colour
Black
Chassis Construction Materials
-
Dimensions
268 x 639 x 659 (WxHxD mm)
Package Type
-
Please Note
-
Clearances
Cable Routing Space
34 mm
Colour
Primary Colour
Black
Connectivity
Card Reader
No
Core Chassis Specifications
Edition
ROG Hyperion GR701 BTF Edition
Case Form Factor
Full Tower
Motherboard Form Factor
ATX
E-ATX (Upto 12" x 10.9")
MicroATX
Mini-ITX
Back Connect Compatible
No
Dimensions
Length Depth
268 mm
Width
639 mm
Height
659 mm
Weight
20 kg
Display
Display Included
No
Drive Bays
Max 2 5 Inch Drives
5
Max 3 5 Inch Drives
2
Max 5 25 Inch Drives
0
Hot Swap Drive Bays
No
Expansion Slots
Expansion Slots Pci Slots
9
External Ports
Front I O Usb Type C Ports Total
2
Front I O Usb Type A Ports Total
5
Audio Outputs Inputs
1x output / input comb. (3.5 mm jack, 4-pin, TRRS)
Fan Header
Fan Controller Fan Hub
No
Fans & Filters
Fan Bays
7 x 120/140mm
Fan Controller Hub
Built-in Fan Hub
Dust Filters
Bottom
Front
Top
Fan Support
Case Fan Support Top
120mm Fan (3x), 140mm Fan (3x)
Case Fan Support Rear
120mm Fan (1x), 140mm Fan (1x)
Case Fan Support Front
120mm Fan (3x), 140mm Fan (3x)
Max Number Of Fans
11
120 Mm Fans
7
140 Mm Fans
11
Features
Housing Feedthrough
No
Internal Dimensions
Max Cooler Height
190 mm
Max Gpu Length
460 mm
Max Psu Length Depth
240 mm
I/O, Bays & Expansion
Front Side Top Panel I O
1 x Headphone/Mic Combo
1 x LED Control Button
1 x Reset Button
4 x USB 3.2 Gen1 Type-A
1 x USB 3.2 Gen2 Type-C
Drive Bays
5 x 2.5" Internal
2 x 2.5"/ 3.5" Internal
Standard Expansion Slots
9
Vertical Expansion Slots
3
LED Lighting Functionality
Led Lighting
Yes
Led Lighting Emitters
Front Panel Addressable RGB LED Lighting
Led Lighting Colour
RGB
Led Lighting Support Control
Compatible with ASUS AURA Sync
Lighting
Lighting Rgb
Yes
Liquid Cooling Support
Front Radiator Compatibility
1 x 120/140/240/280/360/
420mm
Top Radiator Compatibility
1 x 120/140/240/280/360/
420mm
Bottom Radiator Compatibility
-
Rear Radiator Compatibility
1 x 120/140mm
Side Radiator Compatibility
-
Motherboard Support
Compatible Motherboard Formats
E-ATX, ATX, Micro-ATX, Mini-ITX
Max Motherboard Format
E-ATX
Mounting
Internal Monitor Mount
No
Case Vesa Mountable
No
Power Supply
Psu Included
No
Psu Format
ATX
Power Supply Position
rear bottom
Power Supply Compatibility
Psu Wattage If Included
-
Psu 80 Rating If Included
-
Psu Support
ATX
Psu Mounting Location
Bottom Mount, Rear
Max Psu Length
240 mm
Radiator Support
Radiator Aio Support Rear
120mm Radiator, 140mm Radiator
Max Radiator Compatibility
1x Triple (420 mm)
Radiator Aio Support Front
120mm Radiator, 140mm Radiator, 240mm Radiator, 280mm Radiator, 360mm Radiator, 420mm Radiator
Radiator Aio Support Top
120mm Radiator, 140mm Radiator, 240mm Radiator, 280mm Radiator, 360mm Radiator, 420mm Radiator
Side Panels
Window S
Yes
Window Configuration
1 x Alternate Side
1 x Main Side
Window Construction
Tempered Glass
Best indexed price
£521.61GBP
Indexed 25 May 2026 — verify at retailer
