Power SuppliesAntec
Antec HCG 1000 Pro 1000W ATX 3.1 PCIe 5.1 80 Plus Platinum Modular Power Supply
MPN: 0-761345-20014-1
Key specifications
Wattage1000 W
Form factorATX
ModularYes
Efficiency80 PLUS Platinum
Depth140 mm
Retailer offers
Amazon UKProduct link
Find on AmazonMore retailers coming
We only list a retailer once we hold verified offer data for it. No placeholder prices, ever.
Indexed prices are snapshots, not live quotes. Confirm price, stock and delivery on the retailer's site — checkout completes there.
We may earn a commission from these links. How it works
Fit check
Add this to your build in the PC Builder to automatically check dimensions, sockets, and power draw.
Same specs for less
- Corsair SF Series (2024) 1000 Watt Fully Modular 80 PLUS Platinum PCIe 5.1 SFX PSU/Power Supply£110.87at eBay UK£31.01 less
1000W · same or better efficiency rating
- Montech TITAN PLA 1000W 80+ Platinum Fully Modular ATX 3.1 Power Supply/PSU£135.46at Scan£6.42 less
1000W · same or better efficiency rating
Matched on the listed specs that matter for this kind of part, at each listing's lowest new price. Other details (cooling, warranty, looks) can differ.
Related Products
Full Specifications79 fields
Additional Information
Model Number
0-761345-20014-1
Gtin
761345200141
Certificates
Certification
cTUVus/TUV/CB/RCM/CE/
FCC/BIS/BSMI/KC/UKCA/
ICES/CCC
Design
Product Colour
Black
Type
Active
Fan Diameter
13.5 cm
Number Of Fans
1 fan(s)
Fan Location
Top
On Off Switch
Yes
Efficiency Class
80plus Efficiency
80 PLUS Platinum
Operational conditions
Operating Temperature T T
0 - 40 °C
Packaging data
Package Width
198 mm
Package Depth
336 mm
Package Height
133 mm
Package Weight
3.97 kg
Package Type
Box
Performance
80 Plus Certification
80 PLUS Platinum
Purpose
PC
Power Supply Unit Psu Form Factor
ATX
Atx Version
3.1
Silent Mode
Yes
Ports & interfaces
Motherboard Power Connector
20+4 pin ATX
Motherboard Power Cable Length
61 cm
Number Of Sata Power Connectors
14
Sata Power Cable Length
150,400,500 mm
Peripheral Molex Power Connectors 4 Pin
3
Peripheral Molex Power Cable Length
100,450 mm
Pci Express Power Connectors 6 2 Pin
3
Pci Express Power Connectors 12 4 Pin
1
Cpu Power Connector 4 4 Pin
Yes
Cpu Power Cable Length
70 cm
Atx Power Connector 20 4 Pin
Yes
Cabling Type
Fully-Modular
Power
Total Power
1000 W
Ac Input Voltage
100 - 240 V
Ac Input Frequency
50/60 Hz
Input Current
13 - 6.5 A
Power Factor Correction Pfc Type
Active
Combined Power 3 3v
125 W
Combined Power 12v
996 W
Combined Power 5v
125 W
Combined Power 12v
3.6 W
Combined Power 5vsb
15 W
Max Output Current 3 3v
25 A
Max Output Current 12v
83 A
Max Output Current 5v
25 A
Max Output Current 12v
0.3 A
Max Output Current 5vsb
3 A
Power Protection Features
No load operation, Over current, Over power, Over voltage, Short circuit, Surge & inrush protection (SIP), Under voltage
Specifications
Form Factor
ATX 3.1
Edition
HCG1000 Pro Platinuium ATX3.1
Wattage
1000 W
Energy Efficiency Certification
80 PLUS Platinum
Max Efficiency At 230vac
94 %
Cooling
Fan
Fans
1 x 135mm
Internal 12v Rails
Single Rail
Rail 1 12v
83 A
Rail 2 12v
N/A
Rail 3 12v
N/A
Rail 4 12v
N/A
Rail 5 12v
N/A
Rail 6 12v
N/A
Max Combined Output 12v
83 A
Modular
Yes
Modularity
Full Modular
Sli Crossfire
No
Eps 12v
No
Motherboard Connector
24-pin
Connectors
1 x 16-pin PCIe
2 x 4+4-pin ATX 12V
3 x 4-pin Molex
3 x 6+2-pin PCIe
14 x SATA
Dimensions
160 x 86 x 140 (WxHxD)
Warranty
10 Year
Weight & dimensions
Width
150 mm
Depth
160 mm
Height
86 mm
Weight
3.39 kg
